Loxone Audio Server

The Loxone Audioserver is the most flexible audio solution for any type of building. With four integrated amplifier outputs, it delivers brilliant sound for all wired speakers. The system is virtually infinitely expandable with stereo extensions and additional audioservers, allowing you to create individually configurable multiroom audio zones.

Various music sources, including streaming services, can be used via USB, line-in, and network. Configuration is conveniently done via Loxone Config; the hardware is maintenance-free and energy-efficient.

Technical data

• 4 amplifier outputs, each with up to 50 W peak power
• Supports passive loudspeakers 4–8 Ω
• Sampling rate up to 192 kHz
• Power supply: 18–26 VDC
• Power consumption: approx. 6.7 W (max. load)
• Dimensions (L x W x H): 157 x 88 x 57 mm
• Weight: 270 g net, 225 g net according to some sources (average 270 g acceptable)
• Mounting on a top-hat rail (DIN rail)


Scope of delivery

• 1× Loxone Audioserver
• 1× Assembly instructions
